SUN LOUVER SYSTEM

Sun Louver system is very versatile and is suitable for industrial and commercial buildings. Their purpose can be to control light, to provide ventilation while maintaining rain defense, to provide screening or a combination of these. Louvers can also be designed and installed just for aesthetic effect.

​

The sun louver system is a unique system using just 2 components: standard roll formed panels and stringers. The stringer height can be adjusted to ensure optimal shading angles without affecting natural wind flow.

​

Panel Specifications:

Material: Aluminium Alloy 3003 H24

Thickness: 0.5mm/0.7mm

Length: Customize

Coating: 2 coats of PVDF with a thickness of 28 microns and primer or base coat at the back of the panels

​

Stringer Specifications:

Material: Aluminium Alloy 5052 H34 polyurethane coated white or black colour

Thickness: 1.0mm/1.5mm

​
